AUTOTERM Air 4D Marine Large Set (12V)
ASSY
12346
Copied
Marine set: Large
Boats/Yachts: Max 48ft/15m
Heating power: 4 kW
Voltage: 12V
Fuel: Diesel
Control unit with High Altitude Sensor
Technical specifications
| Technical characteristics |
High
Low
|
Rated voltage |
12V
|
| Heating medium |
Air
|
Heat power |
4.0 kW
1.0 kW
|
| Heated air volume |
168 m3/h
70 m3/h
|
Rated power consumption |
57 W (12V) / 56 W (24V)
10 W
|
| Max. work altitude (MASL) |
4200 m (High altitude control unit)
|
Max. boat/yacht length |
48ft / 15m
|
| Fuel |
Diesel - EN590
HVO100 - EN15940
|
Fuel consumption |
0.51 l/h
0.12 l/h
|
| Control mode |
Manual, standard remote control, modem
|
Compatible control panels |
Simple Control, OLED Control panel, Comfort Control
|
| Weight of the heater |
5.5 kg
|
Weight of the marine set |
15.5 kg
|
| Heater dimensions |
402x157x188 mm
|
Marine package dimensions |
600x400x720 mm
|
Included and compatible items
