Comfort
Boiler Control Panel
This control panel provides intuitive operation for both Air and Flow Series heaters paired with all AUTOTERM combiBOIL models. It offers multiple operating modes, advanced timers, multilingual support, and built-in frost protection, making it the perfect solution for managing both air, engine and water temperatures with ease.
Note! The regular Comfort Control Panels cannot be upgraded to match Comfort Boiler Control functions.
WORKMODES WITH AIR SERIES
Comfort Control allows to set multiple workmodes and advanced timers on all AUTOTERM Air Series heaters.
TEMPERATURE MODE
The heater will maintain a set temperature by reducing the heating power, without shutting off the combustion process.
POWER MODE
The heater will operate constantly at a set power level.
HEAT + VENTILATION
The heater runs until the temperature reaches 1°C above the set point, then shuts off and ventilates until it drops 5°C below before resuming to heat.
THERMOSTAT MODE
The heater runs until the set temperature is reached, then shuts off and restarts heating when the temperature drops.
WORKMODES WITH FLOW SERIES
Comfort Control enables advanced timers and multiple operating modes for Flow Series heaters.
PRE-HEATING MODE
The heater runs until the coolant reaches a set temperature, then shuts off the combustion process. Heating resumes when the coolant temperature drops.
THERMOSTAT MODE
The heater runs until the set temperature is reached, then shuts off and restarts heating when the temperature drops.
COMPATIBLE WITH ALL combiBOIL & duoBOIL models!
The Comfort Boiler Control provides complete management of all combiBOIL & duoBOIL systems, whether paired with Air or Flow heaters or operating independently on electricity.
Water Heating
The panel displays real-time water temperature and allows adjustment of the target temperature between 50°C and 75°C.
Adjustable Hysteresis
Water heating hysteresis is adjustable 5-20°C from the target temperature.
Frost Protection
When the water temperature drops to 2°C, the heater will automatically heat the water to +15°C and Air to +7°C, protecting the boiler from freezing.
Overheat Protection
Turning off the heating when the water temperature reaches 78°C.
DESIGNED TO ELEVATE THE EXPERIENCE
Absolutely. It fully supports standalone heater operation and allows seamless integration of a boiler later on.
Easily navigate and control your heater with a user-friendly interface designed for simplicity and convenience. Perfect for seamless operation, even on the go!
The digital temperature sensor offers accurate, real-time monitoring, ensuring your heater maintains the perfect temperature for maximum efficiency.
Get instant feedback on your heater's performance with the bright and clear LED screen.
Maintain precise temperature control with the thermostat function, ensuring consistent comfort and energy efficiency.
Customize comfort with multiple heating modes, tailored to suit various needs and conditions.
Protects vehicle’s battery with a built-in safety feature that prevents excessive drain during heater operation, ensuring reliable starts every time.
The heater maintenance reminder helps users stay on top of servicing, alerting them when it’s time for maintenance to maintain optimal efficiency and extend the heater’s lifespan.
This panel supports multiple languages, including EN, NL, DE, PL, ES, IT, FR, CZ, SE, NO, and FI, making it easy to use for a wide range of users across different regions.
SCHEDULED COMFORT
Effortlessly manage your heating schedule with our intuitive timers. Designed for maximum flexibility and convenience, the timer system lets you customize your heating needs with precision.
Set Up To 3 Timers Simultaneously:
Schedule up to three independent timers to match your daily routine.
Heating Mode Options:
Choose a specific heating mode for each timer to suit your preferences.
Continuous Functionality:
Once set, a timer remains active continuously until it's disabled, so you never have to worry about resetting schedules.
Comfort Boiler Control SPECIFICATION
|
Temperature sensor
|
Custom calibrated digital sensor with +/- 1.5 degree offset. |
|
Timers
|
Max - 3 timers. Heating mode can be chosen for each timer. All 3 timers can be active simultaneously. Set timer is active continuously till disabled Available cycles: ED - Every day EW - Every workday Custom days |
|
Status display
|
LED red - heating LED blue - ventilation LED green - shutting down |
|
Wiring compatibility
|
assy.2067 - Wiring for control panel (1.8 m); assy.2324 - Wiring for control panel (5.0 m); assy.3298 - Wiring for control panel (7.0 m); assy.4269 - Extension wiring for control panel (2.6 m); assy.4111 - Extension wiring for control panel (3 m); assy.2468 - Extension wiring for control panel (5 m); assy.4366 - Cable wiring for AUTOTERM Flow 5D (12V); assy.4044 - Cable wiring for AUTOTERM Flow 5D / 5B (12V); assy.4394 - AUTOTERM Flow 14D wiring harness for control panel (1.8 m); (Maximum allowed cable wiring length with Comfort Control - 10 m) |
|
Compatibility with Air Heaters:
|
AUTOTERM Air 2D; AUTOTERM Air 4D; AUTOTERM Air 9D. (for verification of compatibility for older heaters sold by AUTOTERM, please contact us: service@autoterm.com) |
|
Compatibility with Liquid Heaters:
|
AUTOTERM Flow 5D / 5B; AUTOTERM Flow 14D. (for verification of compatibility for older heaters sold by AUTOTERM, please contact us: service@autoterm.com) |
|
AUTOTERM combiBOIL compatibility
|
All 7l, 9l, and 12l combiBOIL versions. |
|
AUTOTERM combiBOIL compatibility
|
All 9l duoBOIL versions. |
|
Display dimensions
|
37x20mm |
|
Control panel dimensions
|
82x37x19mm |
